略略略略~~~..时隔N久..又回来写一篇文章,来记录自己这段时间所做的一些事情…

RecyclerView加载不同布局已经在网上一搜一大把了…为啥我还要在写..不为啥..就因为太久没有使用过RecyclerViewle ..以至于在项目中竟然写Adapter的时候卡壳了…太可怕了…所以来热热手..

• 使用RecyclerView,首先添加依赖:

  compile 'com.android.support:recyclerview-v7:23.0.+'

• Activity 的布局

  <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
      xmlns:tools="http://schemas.android.com/tools"
      android:layout_width="match_parent"
      android:layout_height="match_parent"
      android:orientation="vertical"
      tools:context="www.fl.com.recyclerviewtest.MainActivity">

      <TextView
          android:layout_width="match_parent"
          android:layout_height="40dp"
          android:background="@color/green_title"
          android:gravity="center"
          android:text="RecyclerView显示不同的item" />

      <com.jcodecraeer.xrecyclerview.XRecyclerView
          android:id="@+id/recyclerview"
          android:layout_width="match_parent"
          android:layout_height="0dp"
          android:layout_weight="1" />

  </LinearLayout>

• Activity中的代码

  public class MainActivity extends AppCompatActivity {

      private RecyclerView tRecyclerView;

      private List<Integer> typeList=new ArrayList<>();

      @Override
      protected void onCreate(Bundle savedInstanceState) {
          super.onCreate(savedInstanceState);
          setContentView(R.layout.activity_main);
          initParam();
          initView();
      }

      private void initParam() {
          typeList.add(2);
          typeList.add(3);
          typeList.add(3);
          typeList.add(1);
          typeList.add(4);
      }

      private void initView() {
          tRecyclerView= (RecyclerView) findViewById(R.id.recyclerview);
          TopRecyclerViewAdapter adapter = new TopRecyclerViewAdapter(this, typeList);
          tRecyclerView.setLayoutManager(new LinearLayoutManager(this));
          tRecyclerView.setAdapter(adapter);
      }
  }

• Adapter 代码

  public class TopRecyclerViewAdapter extends RecyclerView.Adapter<RecyclerView.ViewHolder> {

      private final Context context;
      //布局标识集合
      private final List<Integer> typeList;

      //设置常量
      private static final int TYPE_IMG_THREE = 2;
      private static final int TYPE_IMG_RECYCLER = 3;
      private static final int TYPE_IMG_RECYCLER_ONE = 1;
      private static final int TYPE_IMG_RECYCLER_FOUR = 4;

      public TopRecyclerViewAdapter(Context context, List<Integer> typeList) {
          this.context = context;
          this.typeList = typeList;
      }

      /**
       * 根据不同的position，设置不同的ViewType
       * position表示当前是第几个Item，通过position拿到当前的Item对象，然后判断这个item对象需要那种视图
       */
      @Override
      public int getItemViewType(int position) {
          if (typeList.get(position) == 2) {
              return TYPE_IMG_THREE;
          } else if (typeList.get(position) == 3) {
              return TYPE_IMG_RECYCLER;
          } else if (typeList.get(position) == 1) {
              return TYPE_IMG_RECYCLER_ONE;
          } else if (typeList.get(position) == 4) {
              return TYPE_IMG_RECYCLER_FOUR;
          }
          return 0;
      }

      //重写onCreateViewHolder方法，返回一个自定义的ViewHolder(当RecyclerView需要一个ViewHolder时会回调该方法，如果有可复用的View不会回调)
      @Override
      public RecyclerView.ViewHolder onCreateViewHolder(ViewGroup parent, int viewType) {

          if (viewType == TYPE_IMG_THREE) {
              View view = LayoutInflater.from(parent.getContext()).inflate(R.layout.item_recyclerview_three, parent, false);
              ThreeViewHolder threeViewHolder = new ThreeViewHolder(view);
              return threeViewHolder;
          } else if (viewType == TYPE_IMG_RECYCLER) {
              View view = LayoutInflater.from(parent.getContext()).inflate(R.layout.item_recyclerview_hrecyclerview, parent, false);
              RecyclerViewHolder recyclerViewHolder = new RecyclerViewHolder(view);
              return recyclerViewHolder;
          } else if (viewType == TYPE_IMG_RECYCLER_ONE) {
              View view = LayoutInflater.from(parent.getContext()).inflate(R.layout.item_recycleview_one, parent, false);
              RecycleViewHolderOne recycleViewHolderOne = new RecycleViewHolderOne(view);
              return recycleViewHolderOne;
          } else if (viewType == TYPE_IMG_RECYCLER_FOUR) {
              View view = LayoutInflater.from(parent.getContext()).inflate(R.layout.item_recycleview_four, parent, false);
              RecycleViewHolderFour recycleViewHolderFour = new RecycleViewHolderFour(view);
              return recycleViewHolderFour;
          }
          return null;
      }

      //填充onCreateViewHolder方法返回的holder中的控件(当一个View需要出现在屏幕上时，该方法会被回调，我们需要再该方法中根据数据来更改视图)
      @Override
      public void onBindViewHolder(RecyclerView.ViewHolder holder, int position) {
          if (holder instanceof ThreeViewHolder) {
              setFloorTwo((ThreeViewHolder) holder, position);
          } else if (holder instanceof RecyclerViewHolder) {
              setFloorThree((RecyclerViewHolder) holder);
          } else if (holder instanceof RecycleViewHolderOne) {
              setOnePic((RecycleViewHolderOne) holder);
          } else if (holder instanceof RecycleViewHolderFour) {
              setFourPic((RecycleViewHolderFour) holder);
          }
      }


      //获取数据的数量(告诉RecyclerView有多少个视图需要显示)
      @Override
      public int getItemCount() {
          return typeList.size();
      }

      private void setFourPic(RecycleViewHolderFour holder) {

          holder.iv_one.setImageResource(R.color.colorAccent);
          holder.iv_two.setImageResource(R.color.colorPrimary);

      }

      private void setOnePic(RecycleViewHolderOne holderOne) {
          holderOne.imageView.setImageResource(R.color.colorPrimary);

      }

      //设置二楼数据（显示3张图片）
      private void setFloorTwo(ThreeViewHolder holder, int position) {
          holder.tvTitle.setText("这里显示三张图片");
      }

      //设置三楼数据（显示N张图片）
      private void setFloorThree(RecyclerViewHolder holder) {
          setHRecyclerView(holder.hRecyclerView);
      }

      private void setHRecyclerView(RecyclerView hRecyclerView) {

          HRecyclerViewAdapter hRecyclerViewAdapter = new HRecyclerViewAdapter(context);
          LinearLayoutManager layoutManager = new LinearLayoutManager(context);
          layoutManager.setOrientation(OrientationHelper.HORIZONTAL);
          hRecyclerView.setLayoutManager(layoutManager);
          hRecyclerView.setHasFixedSize(false);
          hRecyclerView.setAdapter(hRecyclerViewAdapter);

          hRecyclerViewAdapter.setOnItemClickListener(new HRecyclerViewAdapter.OnItemClickListener() {
              @Override
              public void onItemClick(int position) {
                  Toast.makeText(context, "你点击了" + position + "条", Toast.LENGTH_SHORT).show();
              }
          });
      }

      //三张图片
      public class ThreeViewHolder extends RecyclerView.ViewHolder {

          public TextView tvTitle;
          public ImageView ivOne, ivTwo, ivThree;

          public ThreeViewHolder(View itemView) {
              super(itemView);
              tvTitle = (TextView) itemView.findViewById(R.id.tv_title);
              ivOne = (ImageView) itemView.findViewById(R.id.iv_one);
              ivTwo = (ImageView) itemView.findViewById(R.id.iv_two);
              ivThree = (ImageView) itemView.findViewById(R.id.iv_three);
          }

      }

      //横向的RecyclerView
      public class RecyclerViewHolder extends RecyclerView.ViewHolder {

          public TextView tvTitle;
          public RecyclerView hRecyclerView;

          public RecyclerViewHolder(View itemView) {
              super(itemView);
              tvTitle = (TextView) itemView.findViewById(R.id.tv_title);
              hRecyclerView = (RecyclerView) itemView.findViewById(R.id.h_recyclerview);
          }
      }


      public class RecycleViewHolderOne extends RecyclerView.ViewHolder {

          ImageView imageView;

          public RecycleViewHolderOne(View itemView) {
              super(itemView);
              imageView = (ImageView) itemView.findViewById(R.id.iv_show_one);
          }
      }

      public class RecycleViewHolderFour extends RecyclerView.ViewHolder {
          ImageView iv_one, iv_two;

          public RecycleViewHolderFour(View itemView) {
              super(itemView);
              iv_one = (ImageView) itemView.findViewById(R.id.iv_one);
              iv_two = (ImageView) itemView.findViewById(R.id.iv_two);
          }
      }
  }

• 横向的RecyclerView 的Adapter

  public class HRecyclerViewAdapter extends RecyclerView.Adapter<HRecyclerViewAdapter.HImageHolder>{

      private final Context context;
      private OnItemClickListener onItemClickListener;

      public HRecyclerViewAdapter(Context context) {
          this.context=context;
      }

      @Override
      public HImageHolder onCreateViewHolder(ViewGroup parent, int viewType) {
          View view = LayoutInflater.from(context).inflate(R.layout.item_hrecyclerview_recyclerview_home, parent, false);
          HImageHolder hImageHolder = new HImageHolder(view);
          return hImageHolder;
      }

      @Override
      public void onBindViewHolder(final HImageHolder holder, int position) {


          if (onItemClickListener!=null){
              holder.itemView.setOnClickListener(new View.OnClickListener() {
                  @Override
                  public void onClick(View v) {
                      onItemClickListener.onItemClick(holder.getLayoutPosition());
                  }
              });
          }

      }

      @Override
      public int getItemCount() {
          return 10;
      }

      public class HImageHolder extends RecyclerView.ViewHolder{

          public ImageView imageView;
          // 折扣 名字 价格
          public TextView tvDiscount,tvName,tvPrice;

          public HImageHolder(View itemView) {
              super(itemView);
              imageView= (ImageView) itemView.findViewById(R.id.imageview);
              tvDiscount= (TextView) itemView.findViewById(R.id.tv_discount);
              tvName= (TextView) itemView.findViewById(R.id.tv_name);
              tvPrice= (TextView) itemView.findViewById(R.id.tv_price);
          }
      }

      public void setOnItemClickListener(OnItemClickListener onItemClickListener){
          this.onItemClickListener=onItemClickListener;
      }

      public interface OnItemClickListener{
          void onItemClick(int position);
      }

  }
