1.问题

目前：当线上出现问题需上kibana上去查询es上收集的log4j2日志。

缺陷：

1. 在多个服务相互调用下，若出现Error级别日志时，无法快速准确定位到由哪个服务引起，只能根据日志时间模糊去定位。
2. log4j2没有配置传入参数，无法准确的复现错误。

改进：

优化：

1. 引入skywalking的traceId，能够显示出完整的链路调用。
2. 收集 请求ip、请求参数、请求路径、返回状态码(属于业务状态码，并不是http状态码，例如Result类中的code)，返回数据等信息。定义log规范，在es上建立所需要的索引，则可解决上述缺陷问题。

2.效果：

先看看我们定义返回数据的格式

public class ResultData<T> {
    private int code;
    private T data;
    private String message;
    //.....
}

需要请求的接口：

  @PostMapping("/check")
    public ResultData getMapping(@RequestBody Tag tag) {
        if(StringUtils.isEmpty(tag.getValue())){
            ResultData<Object> result = ResultData.newError(40000);
            result.setMessage("value不能为空");
            return result;
        }
        return ResultData.newSuccess(tag);
    }

log4j2内定义的格式，这边可以统一规范后给es做索引。

<PatternLayout pattern="%d{yyyy-MM-dd HH:mm:ss.SSS} [%-5level] traceId=%traceId status=%X{status} uri=%X{uri} [ip=%X{ip} 参数=%X{param} 返回=%X{responseBody}] %m %n"/>

效果(由于该demo没有引入skywalking的agent包，所以traceId没有显示)：

请求：{“key”: “name”,“value”: “张三”}

日志：

请求{“key”: “name”}

如果遇到异常也会将请求参数等信息打印出，方便定位：

3.实现

这里先列出该项目的依赖

  <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
            <exclusions>
                <exclusion>
                    <groupId>org.springframework.boot</groupId>
                    <artifactId>spring-boot-starter-logging</artifactId>
                </exclusion>
            </exclusions>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-log4j2</artifactId>
        </dependency>
        <!--若出现Caused by: java.lang.ClassNotFoundException: com.lmax.disruptor.EventFactory导入该jar包-->
<!--        <dependency>-->
<!--            <groupId>com.lmax</groupId>-->
<!--            <artifactId>disruptor</artifactId>-->
<!--            <version>3.4.2</version>-->
<!--        </dependency>-->

        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
        </dependency>

通过Filter拦截请求

import lombok.extern.slf4j.Slf4j;
import org.apache.tomcat.util.http.fileupload.servlet.ServletFileUpload;
import org.slf4j.MDC;
import org.springframework.http.HttpMethod;
import org.springframework.stereotype.Component;
import org.springframework.util.StringUtils;
import org.springframework.web.filter.OncePerRequestFilter;

import javax.servlet.*;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletRequestWrapper;
import javax.servlet.http.HttpServletResponse;
import javax.servlet.http.HttpServletResponseWrapper;
import java.io.*;
import java.util.Arrays;
import java.util.List;

/**
 * 拦截请求信息，添加到日志
 */
@Component
@Slf4j
public class MDCFilter extends OncePerRequestFilter {
    private static final String STATUS = "status";
    private static final String IP = "ip";
    private static final String URI = "uri";
    private static final String PARAM = "param";
    private static final String RESP_BODY = "responseBody";
    @Override
    protected void doFilterInternal(HttpServletRequest request, HttpServletResponse response, FilterChain chain) throws ServletException, IOException {
        try {
            //因为是threadlocalMap，需要clear()，不在finally中写的原因是 如果在doFilter抛出异常MDC还没写入log就被清空掉，无法打印出抛出异常的链路信息。
            MDC.clear();
            String uri = request.getRequestURI();
            //如果是文件的话则不记录 有可能会过滤表单
            if (ServletFileUpload.isMultipartContent(request)) {
                chain.doFilter(request, response);
                return;
            }
            String query = request.getQueryString() != null ? "?" + request.getQueryString() : "";
            MDC.put(URI, uri);
            MDC.put(IP, request.getRemoteAddr());
            ResponseWrapper wrapperResponse = new ResponseWrapper(response);
            String code = "";
            if (request.getMethod().equals(HttpMethod.POST.name())) {
                MultiReadHttpServletRequest multiReadHttpServletRequest = new MultiReadHttpServletRequest(request);
                //POST BODY参数
                String requestBody = multiReadHttpServletRequest.getRequestBody();
                MDC.put(PARAM, requestBody);
                log.info("");
                chain.doFilter(multiReadHttpServletRequest, wrapperResponse);
            } else {
                MDC.put(PARAM, query);
                log.info("");
                chain.doFilter(request, wrapperResponse);
            }

            byte[] bytes = wrapperResponse.getBytes();
            String responseBody = new String(bytes);
            //还需要重新写入response中
            response.getOutputStream().write(bytes);

            //确保返回不是 void
            if (!StringUtils.isEmpty(responseBody)) {
                code = getCodeOrStatus(responseBody);
                MDC.put(STATUS, code);
                MDC.put(RESP_BODY, responseBody);
                log.info("");
            }
        } catch (Exception e) {
            throw e;
        }
    }


    /**
     * 获取status或者code的业务状态码
     *
     * @param responseBody
     * @return
     */
    private String getCodeOrStatus(String responseBody) {
        //由于多个项目可能有拥有不同的业务状态码
        //json格式的数据以,或者}结尾。
        return KmpUtils.search(responseBody, Arrays.asList("\"status\":", "\"code\":"), Arrays.asList(',', '}'));
    }

    /**
     * HttpServletRequest 请求体多读
     */
    class MultiReadHttpServletRequest extends HttpServletRequestWrapper {

        // 缓存 RequestBody
        private String requestBody;

        MultiReadHttpServletRequest(HttpServletRequest request) {
            super(request);
            requestBody = "";
            try {
                StringBuilder stringBuilder = new StringBuilder();
                InputStream inputStream = request.getInputStream();
                byte[] bs = new byte[1024];
                int len;
                while ((len = inputStream.read(bs)) != -1) {
                    stringBuilder.append(new String(bs, 0, len));
                }
                requestBody = stringBuilder.toString();
            } catch (IOException e) {
                e.printStackTrace();
            }
        }


        @Override
        public ServletInputStream getInputStream() throws IOException {
            final ByteArrayInputStream byteArrayInputStream = new ByteArrayInputStream(requestBody.getBytes());

            return new ServletInputStream() {
                @Override
                public int read() throws IOException {
                    return byteArrayInputStream.read();
                }

                @Override
                public boolean isFinished() {
                    return byteArrayInputStream.available() == 0;
                }

                @Override
                public boolean isReady() {
                    return true;
                }

                @Override
                public void setReadListener(ReadListener readListener) {

                }
            };
        }

        @Override
        public BufferedReader getReader() throws IOException {
            return new BufferedReader(new InputStreamReader(this.getInputStream()));
        }

        String getRequestBody() {
            return requestBody;
        }
    }

    class ResponseWrapper extends HttpServletResponseWrapper {

        private ByteArrayOutputStream bytes = new ByteArrayOutputStream();
        private HttpServletResponse response;
        private PrintWriter printWriter;

        public ResponseWrapper(HttpServletResponse response) {
            super(response);
            this.response = response;
        }

        @Override
        public ServletOutputStream getOutputStream() throws IOException {
            return new MyServletOutputStream(bytes); // 将数据写到 byte 中
        }

        /**
         * 重写父类的 getWriter() 方法，将响应数据缓存在 PrintWriter 中
         */
        @Override
        public PrintWriter getWriter() throws IOException {
            try{
                printWriter = new PrintWriter(new OutputStreamWriter(bytes, "utf-8"));
            } catch(UnsupportedEncodingException e) {
                e.printStackTrace();
            }
            return printWriter;
        }

        /**
         * 获取缓存在 PrintWriter 中的响应数据
         * @return
         */
        public byte[] getBytes() {
            if(null != printWriter) {
                printWriter.close();
                return bytes.toByteArray();
            }

            if(null != bytes) {
                try {
                    bytes.flush();
                } catch(IOException e) {
                    e.printStackTrace();
                }
            }
            return bytes.toByteArray();
        }

        class MyServletOutputStream extends ServletOutputStream {
            private ByteArrayOutputStream outputStream;

            public MyServletOutputStream(ByteArrayOutputStream outputStream) {
                this.outputStream = outputStream;
            }

            @Override
            public void write(int b) throws IOException {
                outputStream.write(b); // 将数据写到 stream　中
            }

            @Override
            public boolean isReady() {
                return true;
            }

            @Override
            public void setWriteListener(WriteListener writeListener) {
            }
        }
    }

    public static class KmpUtils {
        /**
         * 获取kpm数组
         *
         * @param b 原字符串
         * @return
         */
        private static int[] getNext(String b) {
            int len = b.length();
            int j = 0;
            //next表示长度为i的字符串前缀和后缀的最长公共部分，从1开始
            int[] next = new int[len + 1];
            next[0] = next[1] = 0;
            for (int i = 1; i < len; i++) {
                //j在每次循环开始都表示next[i]的值，同时也表示需要比较的下一个位置
                while (j > 0 && b.charAt(i) != b.charAt(j)) {
                    j = next[j];
                }
                if (b.charAt(i) == b.charAt(j)) {
                    j++;
                }
                next[i + 1] = j;
            }
            return next;
        }

        /**
         * kmp查找子字符串
         *
         * @param original 原字符串
         * @param find     子字符串
         * @param next     next数组
         * @return
         */
        public static int search(String original, String find, int[] next) {
            int j = 0;
            for (int i = 0; i < original.length(); i++) {
                char charAt = original.charAt(i);
                while (j > 0 && charAt != find.charAt(j)) {
                    j = next[j];
                }
                if (charAt == find.charAt(j)) {
                    j++;
                }
                if (j == find.length()) {
                    return i + 1;
                }
            }
            return -1;
        }

        /**
         * @param responseBody
         * @param findStr       匹配其中之一
         * @param eofCharacters 截止的字符
         * @return
         */
        public static String search(String responseBody, List<String> findStr, List<Character> eofCharacters) {
            //首先先去除第二层括号内的
            //如果后期改造成统一的返回值字段 就不需要做该操作
            int length = 0;
            char[] chars = responseBody.toCharArray();
            StringBuilder sb = new StringBuilder();
            StringBuilder stringBuilder = new StringBuilder();
            for (char aChar : chars) {
                if (aChar == '{') {
                    length++;
                } else if (aChar == '}') {
                    length--;
                } else {
                    //例如有以code为业务状态码的项目和status的项目使用的该功能
                    //防止出现 {"code":200,data:{"user":"张三","status":"冻结"}} 优先匹配到status
                    //导致输出状态码 "冻结"
                    if (length == 1) {
                        sb.append(aChar);
                    }
                }
            }

            String original = sb.toString();
            int[] next = getNext(original);
            for (String s : findStr) {
                int index = search(original, s, next);
                if (index != -1) {
                    int end = original.length();
                    for (Character eofCharacter : eofCharacters) {
                        //...,"code":200} 以}结束
                        //...,“code”:200,"data":...} 这种情况以,结束
                        //因此这边取比较小的下标
                        int i = original.indexOf(eofCharacter, index);
                        if (i > index) {
                            end = Math.min(i, end);
                        }
                    }
                    stringBuilder.append(original.subSequence(index, end));
                    return stringBuilder.toString();
                }
            }
            return stringBuilder.toString().replaceAll("\"","");
        }
    }

}

如果集成skywalking的traceId需要引入该jar包

<dependency>
    <groupId>org.apache.skywalking</groupId>
    <artifactId>apm-toolkit-log4j-2.x</artifactId>
    <version>8.5.0</version>
</dependency>

如果需要开子线程也记录，需要传递ThreadLocalMap。

log4j2可以通过配置

System.setProperty("log4j2.isThreadContextMapInheritable", "true");

详细可以关注InheritableThreadLocal的实现。
